Configuring jenkins with ansible and Jenkins configuration as code on vagrant
Configuring jenkins with ansible and Jenkins configuration as code on vagrant
This repository (https://github.com/rrodolfos/jenkins-single-vagrant-ansible.git) contains vagrant and ansible configuration to deploy and provision a single jenkins server with jenkins configuration as code (a.k.a. JCasC):
DISCLAIMER
This implementation is intended for testing / PoC / playing purposes only, this solution is not scalable or secure enough for live / production environments. Use it at your own risk. Have fun!.
Requirements
The below requirements are needed to deploy and provision Jenkins VM.
what did I use for this?
- MacBook Pro 2015 CPU Core i5 8GB RAM
- OS GNU Linux/Debian 12 Bookworm 64bits
- VirtualBox 6.1.16
- Vagrant 2.2.14
- Vagrant box debian/bullseye64
- Ansible 2.10.8
Included content
- Vagrantfile
- ansible.cfg
- Playbook.yml
- Roles
- common
- jenkins
Vagrantfile
VM machine definition as follow:
- jenkins
- 2 vcpu
- 1024 RAM
- 192.168.33.12 VM ip address
How to build it
Jenkins
This VM deploy a single Jenkins server as follow (by ansible):
- Install Jenkins dependencies
- Copy Jenkins default configuration
- Create Jenkins home
- Create init.groove.d directory with the configuration file (Groovy Hook Scripts) for modules instalation (JCasC among them) into jenkins home
- Copy jenkins.yml for JCasC and “automagically” configuration into jenkins home
- Install Jenkins
- Remove jenkins.yml
- Have fun!
Clone this repository
$ git clone https://github.com/rrodolfos/jenkins-single-vagrant-ansible.git
Change to the cloned repository directory
$ cd jenkins-single-vagrant-ansible
Create vagrant VM and deploy jenkins
To start up the VM
$ vagrant up
Coffee time!. On a MacBook Pro 2015 and 100Mbps bandwidth it took ~6 minutes. Vagrant box downloading (base linux distro) not included.
Check the VM
To connect to the VM (ssh)
$ vagrant ssh
Connect to Jenkins
To connect via web browser
http://192.168.33.12:8080/
Username: admin
Password: admin
Destroy vagrant VM
To destroy the VM
$ vagrant destroy
Author
Rodolfo Sauce-Guinand - rrodolfos gmail com
